Retain wall 3.115m L x 450mm T rnd steps
How To Assemble A Corten Retaining Wall
Need a layout drawing for a different sized retaining wall?
Email us the size and we will get back to you with a suggested layout
[email protected]It is recommended to seal the internal steel that will be in contact with the soil, with a bitumen damp proof membrane. This will increase the lifespan of the wall.
Full Kitset
Parts List
| Part | Quantity |
|---|---|
| Corten Squ End Cap V 447 x 200mm | 2 |
| 90deg 50mm round corner joiner int-450 | 1 |
| Qtr Ext Cur 600mm rad 297mm A=942mm | 1 |
| Qtr Ext Cur 900mm rad 297mm A=1414mm | 1 |
| Corten Panel 1200 x 450 x 3mm Top | 1 |
| Corten Panel 1500 x 450 x 3mm Top | 2 |
| Corten Angle post FT 897 x 53mm | 3 |
| M8 SS316 nut, bolt, washer (qty 25) | 1 |
